DANNOVO HD 720P PTZ IP High Speed Dome Camera,Outdoor 1.0 MegaPixel CCD,China Dannovo 18x Optical Zoom,Support SD Card Slot,iPhone,Onvif,Two-way Audio,Mobile Phone,BNC Output(DN-HDPTZ03D-MPD)
Main Features
DANNOVO HD 720P PTZ IP High Speed Dome Camera,Outdoor 1.0 MegaPixel CCD,China Dannovo 18x Optical Zoom,Support SD Card Slot,iPhone,Onvif,Two-way Audio,Mobile Phone,BNC Output(DN-HDPTZ03D-MPD):
HD 720P PTZ IP High Speed Dome Camera Features:
1/3" Progressive Scan CCD,Total pixels :1.0Mega, Dannovo 18x Optical Zoom,Horizontal Rotation Range:360 degree;Vertical:90degree;Horizontal Speed:0.1-300 degree/sec,Vertical:0.1-120 degree/sec, Min.Illumination:Color Mode:0.1Lux@F1.6,B/W Mode:0.02Lux@F1.6,Video Compression:H.264MainProfile,Dual Stream,Onvif Protocol,Mobile Phone,Max.Resolution:1280x720,Dual IR-Cut filter,High-strength aluminum shell,Water and Dust Resistance:IP66.
> 1/3" Progressive Scan CCD,Total pixels :1.0Mega;
> Dannovo 18x Optical Zoom;
> Max.Resolution: 1280x720;
> Min.Illumination:Color Mode:0.1Lux@F1.6;B/W Mode:0.02Lux@F1.6;
> Focal Length:f=4.7mm(W)-84.6mm(T);
> Horizontal Range:360°Continuous Rotation,Vertical Range:90°(Auto Flip);
> Horizontal Speed:0o-300o/s,Vertical Speed:1o-120o/s;
> Support Micro SDHC Card for Storage;
> Dual IR-Cut filter for Day/Night Switching;
> Dual-streaming:H.264 and MJPEG;
> Preset Positions: 256,Precision±0.1°;
> Support BNC Output,OSD Menu;
> Aluminum Shell,IP66 Outdoor waterproof;
> Support Two-way Audio,Motion Detection,Alarm;
> RTSP;
> Support Onvif Protocol,iPhone,Android etc Mobile Viewing;
> H.264 Main Profile@Level 3, realize transmission of High Definition video over low network bandwidth easily;
> Upto 10viewers can directly access the camera simultaneously;
> Built-in Web server enables the use of a standard Web browser for viewing and management;
> Support remote control and view ip camera;
> Support remote software upgrade;
> Support dynamic IP address , LAN, Internet (ADSL and Cable Modem);
> Support protocals: RTSP, RTP, HTTP, TCP/IP, UDP, SMTP, PPPoE, DDNS, DNS, SNTP,DHCP, FTP,SNMP;
> 1ch Mic input and 1ch linear audio output;
> Auto-adjusting frame rate according to realtime network rate;
> Alarm recording: video lost, motion detection and sensor alarm;
> Provide RS485/RS232 serial port with several built-in high-speed domes and decoder protocols, supports transparent protocols;
> Auto-recovery after exception occurs or the network being reconnect.
Optional Models:
| Model | DN-HDPTZ03H-MPD | DN-HDPTZ03D-MPC | DN-HDPTZ03D-MPD | |
| Camera Module | Hitachi | Dannovo | Dannovo | |
| Sensor | 1/3"Progressive Scan CCD | 1/3"Progressive Scan CMOS | 1/3"Progressive Scan CCD | |
| Effective Highest Resolution | 1280(H)×960(V) | 1280(H)×720(V) | 1280(H)×720(V) | |
| Camera Lens | Hitachi 18x Optical X 12x Digital Zoom | Dannovo 18x Optical X10x Digital Zoom | Dannovo 18x Optical Zoom | |
| Min.Illumination |
Color : |
Color Mode:0.2Lux@F1.6, B/W:0.02Lux@F1.6 |
Color Mode:0.1Lux@F1.6, B/W:0.02Lux@F1.6 | |
 |
 |
 |
|
 |
|||
HD 720P PTZ IP High Speed Dome Camera Model |
DN-HDPTZ03D-MPD | |
| Camera Module | Dannovo | |
| Sensor | 1/3"Progressive Scan CCD | |
| Effective Highest Resolution | 1280(H)×720(V) | |
| Camera Lens | Dannovo 18x Optical Zoom | |
| Min.Illumination | Color Mode:0.1Lux@F1.6,B/W Mode:0.02Lux@F1.6 | |
| Focal Length | f=4.7mm(W) ~ 84.6mm(T) | |
| Iris | F1.6 ~F2.8 | |
| Horizontal Angle of View | 55.2°(W)~3.2°(T) | |
| Day/night | Auto (Dual IR-Cut filter) | |
| S/N | ≥50db(AGC OFF) | |
| Parameters adjustment | AWB,AGC,BLC | |
| Auto Electronic Shutter | 1/25—1/10000sec,Slow shutter:1/2,1/4,1/8,1/12sec | |
| Network chip | Lan | Realtek 10/100M BASE-TX Self-adapting |
| Interfaces | ||
| Audio Talkback | 1 channel MIC input,3.5mm connector | |
| Audio Output | 1 channel Output,3.5mm connector | |
| Video Output | 1 channel BNC Output | |
| Network Interface | Lan | 10/100M BASE-TX,RJ-45 connector |
| I/O | 1-channel input, Normally Open/Normally Close modes adjustable; 1-channel output, 120VAC 1A/24VDC 1A | |
| Storage Interface | Micro SD card supports video storage and image snapping; SD2.0 standard, maximum storage 32G | |
| Audio video encoding | ||
| Video Compression | H.264 Main Profile | |
| MJPEG/JPEG Baseline | ||
| Resolution | Master Streaming | 1280x720,1-25(30)fps/sec |
| Second Streaming | 640*480,1-25fps/sec;320*240,1-25fps/sec;160*112,1-25fps/sec | |
| Video Bitrate | 32Kbps~16Mbps,Supports CBR/VBR | |
| Title OSD | Supports channel name, date, and video stream information overlay; OSD location is adjustable | |
| Audio Compression | G.726,G7.11A,G.711U,AAC,Support 32 K Stereo | |
| Data transmission and storage | ||
| Data storage | Video and Image | |
| Recording | Manual | |
| Alarm Output | E-mail, Explorer, Software | |
| Network protocol | TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,DDNS,DHCP, FTP,NTP,PPPOE,SMTP,UPNP | |
| ONVIF protocol | Support | |
| Remote View | Computer | IE 6.0 or up, max 16 user |
| Mobile Phone | Support Windows Mobile, Symbian, iPhone, Android platform | |
| General Parameters | ||
| OSD Menu | Support | |
| Water and Dust Resistance | IP66 | |
| Mechanical properties | Horizontal Range | 360°Continuous Rotation |
| Horizontal Speed | 0°~300°/s | |
| Vertical range | 0°~90°(Auto flip) | |
| Vertical speed | 0°~120°/s | |
| Preset speed | 400°/s | |
| Preset precision | ±0.10° | |
| Proportional Zoom | Support | |
| Preset positions | 256 | |
| Patrol | 2 patrols, up to 8 presets per patrol | |
| Pattern | 2 patterns | |
| Power-off Memory | Support | |
| Park Action | Preset / Pattern / Patrol / Pan Tilt scan /Auto | |
| PTZ Display | Support | |
| Timed task | 5-channel periodic launches :Preset / Pattern / Patrol / Pan Tilt scan/Auto | |
| Material | All Aluminum Crust | |
| Operating Temperature | -30℃-+60℃ | |
| Operating Humidity | 0% - 90% | |
| Power | 24VAC 2A | |
| Power Consumption | 35W | |
