Product Name:
DANNOVO HD 1080P USB 3.0 PTZ Camera,Highest Rating,Sony 30x Zoom Video Web Conferencing Camera,Plug & Play,Lync,Skype,Win OS,MAC OS Compliant(DN-HDC30B)
Main Features
DANNOVO HD 1080P USB 3.0 PTZ Camera,Highest Rating,Sony 30x Zoom Video Web Conferencing Camera,Plug & Play,Lync,Skype,Win OS,MAC OS Compliant(DN-HDC30B):
HD 1080P USB 3.0 PTZ Camera Features:
>Adopting 1/2.8 Exmor? Progressive scan CMOS image Sensor;
>Total Pixel:2.41 Megapixels;
>Sony 30x Optical x 12x Digital Zoom;
>Support 1080P/30 Video Output Mode;
>Video Format: YUY2 | 1920x1080P/30, 1280x720/60 ;
>View Angle:65 degree, Focal Length: f=4.6-138.3MM F1.6-4.7;
>Support Image Flip Function;
>Pan/Tilt Rotation Angle: Horizontal 355 degree, Vertical 125 degree;
>Pan Speed:1-200 degree/s; Tilt Speed: 1-150degree/s;
> Standard USB3.0 Video Output, Plug & Play, Support Skype,Lync,Windows OS and MAC OS ;
>PTZ Controlling Protocol: PELCO-D,VISCA;
>Remote Controller for controlling PTZ, Zoom, Preset Position and OSD etc.
 |
 |
 |
|
 |
|||
HD 1080P USB 3.0 PTZ Camera Model No. |
DN-HDC30B | |
| Image Sensor | Sensor | 1/2.8" Type Exmor? Progressive scan CMOS image Sensor |
| Effective Pixels | HD 2.41 Megapixel | |
| Illumination | 1.4 lux (Typ. 50IRE, ICR OFF, AutoAE) | |
| White Balance | Auto/Manual | |
| Gain Control | Auto | |
| Back-light compensation | On / Off | |
| E-Shutter | 1/1~1/10,000S | |
| S/N Ratio | > 50db | |
| Lens | Focus | View Angle:65 degree, Focal Length: f=4.6-138.3MM F1.6-4.7 |
| Iris | Auto/Manual | |
| Zoom | Sony 30x Optical X 12x Digital Zoom | |
| Video Output | USB 3.0 | |
| Video Output Mode | Video Format:YUY2|1920x1080P/30, 1280x720/60 | |
| Communication Interface | EIA/RS232C (Bidirectional) | |
| Communication Control Protocol | PELCO-D,VISCA | |
| Baud Rate | 9600/38400bps | |
| Tour | 4 Line | |
| Preset | 64 | |
| Power-off Protection | Saved scanning or patrol line settings Automatically Before power off | |
| Speed Matching | Slow down camera Pan/Tilt movement speed while camera zooming in | |
| OSD Menu | To change parameters of camera or camera module from OSD Menu | |
| Image Auto Flip | When tilt movement over 90 degree(optioin) | |
| Pan Speed | 1-200 degree per second | |
| Tilt Speed | 1-150 degree per second | |
| Pan Rotation Angle | 0~355 degree | |
| Tilt Rotation Angle | 125 degree | |
| Auto Pan Scan | Support auto pan scan | |
| Boundary Scan | 0-359 degree (programmable) | |
| Remote Controller | IR wireless control P/T/Z | |
| Power Supply | DC12V±10%,2A | |
| Working Temperature | 0-50℃ | |
| Environment Humidity | 0-95%RH | |
