DANNOVO USB Powered HD Camera for Web Video Conferencing,Wide Angle,1080P/720P,Better than Logitech,for Skype,Microsoft Lync(DN-HDC05B1)
Main Features
DANNOVO USB Powered HD Camera for Web Video Conferencing,Wide Angle,1080P/720P,Better than Logitech,for Skype,Microsoft Lync(DN-HDC05B1):
DANNOVO USB Powered HD Camera for Web Video Conferencing Feature:
> USB offers Power, Video and Control Signal;
> 1/2.7 HD Color CMOS,Effective Pixel:2.1Megapixel,Max Resolution:1920x1080;
> Plug & Play type, Free Driver, No Need Extra Video Capture Card,USB Interface:Connect to PC Directly;
> Controlling Camera PT through USB directly;USB Cable Offers Power, Video Signal and Control Signal, more Convenient for Users to Control the Camera on PC Directly, No need to connect by RS232;
> Both USB & RS232 for PC Controlling Purpose;
> Smooth Rotation, Low Noise, Short Self-checking Time, Speed Match;
> Rotation Degree:Pan:355°,Tilt:135° Rotation;
> Rotation Speed P/T Speed: Pan:6-27°/s, Tilt:6-27°/s;
> Lens Angle: 6mm Lens with 60°, 3.8mm Lens with 85°,2.1 Megapixel Lens;
> USB cable:2 meters __ Only USB Output
> Desktop or Ceiling and Wall Mounted Installation
> Remote Controller for Controlling PT;
> Support VISCA Protocol with RS232.
 |
 |
 |
|
 |
|||
USB Powered HD Camera for Web Video Conferencing Model |
DN-HDC05B1 | |
| Image Sensor | Sensor | 1/2.7 HD Color CMOS 2.1Mega Pixel |
| Effective Resolution | 2.1 Mega Pixels | |
| Minimum Illumination | 5.0Lux at F2.0 | |
| White Balance | AUTO | |
| Gain Control | Auto | |
| Back-light Compensation | On/Off | |
| S/N Ratio | > 50dB | |
| Lens | Angle | Lens Angle: 6mm Lens with 60°, 3.8mm Lens with 85° |
| Zoom | Fixed Lens | |
| 6mm/3.8mm Lens Optional | ||
| Video Output | USB 2.0 | |
| Video Output Mode | 1920x1080p/30,1280x720p/31, 800x600, 640x480, 352x288, 320x240 | |
| Control Decoder | Built-in | |
| Communication | USB,RS232C | |
| PT Control Protocol | VISCA | |
| Baud Rate | 9600bps | |
| Preset Position | 32 | |
| Speed Matching Function | Support | |
| Image Flip | Support | |
| Pan Speed | 6-27 degrees/s | |
| Tilt Speed | 6-27 degrees/s | |
| Pan rotation angle | 355 degrees | |
| Tilt rotation angle | 135 degrees | |
| Remoter Control | IR Remote Control P/T | |
| Power | DC 5V + -10%;1A | |
| Temperature and humidity | 0-60 ℃ ,0-95% RH | |
